BITTREE 12G+ Video Distribution Amplifier Frame


The DAF32FX Distribution Amplifier Frame holds up to 32 1-in by 4-out distribution amps housed in a 2RU chassis. Modules are available as coaxial cards or hybrid configurations that join coax with fiber or SMPTE ST 2110-compliant IP network connectivity.

DAF32FX Distribution Amplifier Frame
Bittree FX Modules Are Sold Separately
Up to 32-In x128-Out Channels 2RU
Price $2305.00
Add to Cart


  • The DAF32FX is a 2RU frame which houses the DABFX video distribution amps
  • Up to 32 1-in by 4-out distribution amps per frame
  • Accepts all Bittree FX modules
  • Wideband frame for sd-sdi, and hd-sdi & 4K UHD 12G SDI
  • See thru front cover allows quick status indication
  • Input Coax and SFP
  • Connectors DIN 1.0/2.3, 75 ohm, and SFP
  • Number of inputs up to 32
  • Number of outputs up to 128
  • RoHS Compliant
